SANY integrates a full safety suite across all its telehandlers, and the STH625 is no exception. The machine is ROPS/FOPS certified and includes intelligent load monitoring and operator‑presence systems, mirroring what you’ll find on the STH742 and other models.
+ ROPS / FOPS certified cabin (ISO 3471 / 3449)
+ Load weight monitoring & Load Moment Indicator
+ Integrated reversing camera + distance sensor
+ Hi‑viz seatbelt & seat‑present switch
+ Reversing alarm
+ LED work lights on boom and cab
+ Optional roof & screen guards
Just like the larger SANY models (including STH742), the STH625 cabin is designed for maximum comfort, long working hours, and intuitive machine control.
+ Premium adjustable suspended seat
+ 10-inch touchscreen display with encoder navigation
+ Fully adjustable steering column
+ Bluetooth radio, USB charging, cup/bottle holders
+ Heated rear screen, wipers on all sides
+ Air conditioning for optimal comfort
+ All maintenance and daily checks can be performed from ground level
+ Easy access to filters and hydraulic components
+ DEUTZ engine known for long service life and strong support network
+ 3-year / 3000-hour warranty for peace of mind
+ SANY EVI telematics technology is used to monitor a wide
range of information relating to an individual machine or
an entire fleet. Data is gathered by the onboard controllers
on SANY machines to keep data transferring throughout the
day. If you have a mixed fleet with other OEMs, you can
easily access data for your SANY equipment and other brands
using a telematics API, together in one management system.
+ 3-year / 3000-hour warranty for peace of mind
|
PERFORMANCE PARAMETERS
|
|
Maximum lift capacity
|
2,500 kg
|
|
Lift capacity at maximum height
|
2,000 kg
|
|
Lift capacity at maximum reach
|
800 kg
|
|
Lift height
|
6000 mm
|
|
Carriage crowd angle
|
12°
|
|
Carriage dump angle
|
117°
|
|
Outside turning radius (4WS)
|
3,350 mm
|
|
Auxiliary hydraulic flow
|
80 l/min
|
|
Auxiliary hydraulic pressure
|
270 MPa
|
|
Noise at driving position (55 kW)
|
76 Lpa
|
|
Noise to environment (55 kW)
|
104 Lwa
|
|
|
|
|
DIMENSIONS
|
|
|
Length to front of carriage
|
4,000 mm
|
|
Overall width
|
1,850 mm
|
|
Height over cab without beacon
|
1,920 mm
|
|
Height over cab with beacon
|
2,010 mm
|
|
Wheelbase
|
2,390 mm
|
|
Overall cabin width
|
960 mm
|
|
Ground clearance
|
255 mm
|
|
Turning radius over tyres
|
3,350 mm
|
|
